Pack Mate M180L4-SYB: Automatic 4-Lane Snus Pouch Packaging Machine
The Pack Mate M180L4-SYB represents a pinnacle of automation in the packaging of granular and powdered snus. Engineered as a fully automatic, high-speed four-lane pouch packaging system, this machine integrates the entire packaging process—from film forming and precision dosing to filling, heat sealing, and flat cutting—into one seamless, continuous operation. At its core is a robust back-seal bag-making structure, renowned for its stability and reliability in producing uniform pouches. Driven by an advanced PLC control platform with an intuitive 7-inch touch-screen interface, the M180L4-SYB is designed for operational simplicity, ensuring consistent pouch quality and accurate portion weights batch after batch. Its compact industrial design, coupled with multi-voltage compatibility (220V/380V), makes it an ideal, scalable solution for manufacturers seeking to enhance throughput, ensure repeatable sealing performance, and achieve efficient changeovers to meet diverse snus portion requirements.
Product Features
High-Speed, Multi-Lane Production
The innovative 4-in-1 multi-lane design enables the simultaneous operation of four independent packaging columns. This architecture significantly boosts overall production capacity, allowing manufacturers to meet high-volume demands without the need for additional production lines, all while maintaining exceptional stability in pouch forming and cutting precision.
Precision Dosing System
Equipped with a sophisticated measuring cup backflow metering mechanism, the machine excels in the accurate dispensing of small target weights, typically ranging from 0.4 to 0.6 grams per bag. This system minimizes material spillage by controlling backflow during the dispensing cycle, thereby ensuring superior weight consistency and cleaner filling operations for granular or fine powder snus formulations.
Reliable Heat Sealing Technology
The machine employs clean and secure heat sealing to create strong, hermetic closures for each pouch. This critical feature is essential for preserving product freshness, extending shelf life, and mitigating contamination risks throughout storage and distribution. The sealing form is specifically designed with a clean back (no pattern) and neatly sealed left and right sides, meeting the exacting presentation standards of modern snus products.
Hygienic and Durable Construction
Prioritizing hygiene and longevity, the core structure of the M180L4-SYB is constructed from high-grade stainless steel. This corrosion-resistant material supports compliance with stringent sanitary production standards, facilitates easier and more effective routine cleaning, and ensures the machine’s robustness for demanding, continuous operation in industrial environments.
User-Centric Control Interface
Operation is streamlined through a centralized PLC control system paired with a responsive 7-inch human-machine interface (HMI) touch screen. This setup allows for intuitive parameter setting, real-time monitoring, and quick adjustments. The user-friendly design reduces operator training time and promotes stable, repeatable packaging performance across different production shifts.
Global Power Compatibility
Designed for worldwide deployment, the machine offers flexible dual-voltage power options (220V/380V). This adaptability simplifies installation planning and enhances the equipment’s overall utility, allowing it to be seamlessly integrated into manufacturing facilities across various regions and electrical standards.
Technical Specifications
| Item | Specification |
|---|---|
| Model | M180L4-SYB (Automatic) |
| Machine Type | Fully automatic 4-lane pouch packaging machine (granule/powder), back-seal structure |
| Control System | PLC + HMI |
| Touch Screen | 7 inch |
| Filling Type | Measuring cup backflow metering |
| Packaging Type | Pouch |
| Sealing Type | Heat sealing |
| Sealing Form | No pattern on the back; left and right sealed |
| Packaging Film Width | 120 mm |
| Dosage / Bag | 0.4–0.6 g/bag |
| Packaging Speed | 30–45 bags/min (single column) × 4 columns |
| Machine Dimensions (L×W×H) | 1200 × 800 × 1800 mm |
| Main Material | Stainless steel |
| Power Supply | 220V / 380V |
| Installed Power | 3 kW |
Application Fields
The Pack Mate M180L4-SYB is specifically engineered for the precise portioning and pouch packaging of snus, where consistent small-dose filling and reliable sealing are paramount. It is ideally suited for:
- Dedicated snus pouch production lines handling granular snus and powder-like formulations.
- High-output packaging facilities aiming to scale production capacity efficiently without significantly expanding their physical footprint.
- Manufacturers operating in regulated environments that mandate the use of hygienic, stainless-steel equipment.
- Production plants requiring a dependable, integrated system for forming, sealing, and cutting retail-ready snus portions.
